Moldino (Mitsubishi Hitachi Tool) Deep Radius Evolution
#Grup produk P103692942
Spesifikasi
| Material | Carbide |
|---|---|
| Number of Blades | 2 |
| Dimensions (mm) | Neck R: 4 |
| Overall Length (mm) | 50 |
| Blade Length (mm) | 0.5 |
| Surface Treatment | ATH coat |
| Blade Diameter (mm) | 0.8 |
| Corner Radius R (mm) | 0.2, tolerance: ± 0.005 (center reference) |
| Helix Angle (°) | 30 |
| Interference Angle (°) | 9.67θk |
| Neck Diameter D1 (ɸ mm) | 0.77 |
| Neck Length l2 (mm) | 2 |
| Outer Diameter Dc (ɸ mm) | 0.8 |
| Shank Diameter (mm) | 4 |
| Shank Diameter Tolerance | h5 |
Pilih jenis produk yang diinginkan
| Nomor SKU | Model Number | Masa Persiapan Barang | Harga | Jumlah |
|---|---|---|---|---|
| Loading... | ||||
Apakah produk dengan spesifikasi yang Anda inginkan belum tersedia? Hubungi tim Layanan Pelanggan kami di sini
Informasi Produk
Description
An abundant lineup of 332 items in total! A lineup with a minimum corner R size of 0.02 mm! Heat resistant coating TH has evolved. Adopts a laminated structure to ensure both heat resistance and adhesion strength. Higher hardness (3800HV) than before !! Shows good wear resistance. (Conventional high hardness film hardness: 3600HV) Long life stabilization is realized for cutting high hardness steel such as plastic molds and die casting molds. Improved heat resistance enables longer life in both wet and dry cutting. R accuracy guarantee for high precision machining. Higher precision finishing is possible during die finishing! Evolved composite neck shape Blade shape with improved stability
