Kitz Ductile Made General Purpose F Attached Dish Entrance Globe Valve (10K)
#Grup produk P103050438
Spesifikasi
| Material (stem) | SUS420J2Q |
|---|---|
| Material (Ground) | SUS403 or SUS420J2 |
| Material (Disk holder) | SCS1 |
| Material (bonnet ring) | FCD-S |
| Material (bonnet) | FCD-S |
| Material (Packing nut) | FCD-S |
| Material (Handle) | FCD450-10 |
| Body Material | FCD-S (seat ring/SUS403) |
| Call of pipe flange | 10A(3/8B) |
| Class | 10K |
| Connection Method | Pipe flanges |
| Dimension H (mm) | 108 |
| Dimension L (mm) | 85 |
| Dimensions d (mm) | 60 |
| Handle Shape | circular |
| Material (Gasket) | C1100-0 |
| Material (name plate) | A1050P |
| Nominal Diameter A | 10 |
| Nominal Diameter B | 3/8 |
| Shape | straight |
Pilih jenis produk yang diinginkan
| Nomor SKU | Model Number | Masa Persiapan Barang | Harga | Jumlah |
|---|---|---|---|---|
| Loading... | ||||
Apakah produk dengan spesifikasi yang Anda inginkan belum tersedia? Hubungi tim Layanan Pelanggan kami di sini
Informasi Produk
Warning
Because it is made of copper gasket, it is not suitable for ammonia, amine type fluids.Ulasan Produk
