Kitz Ductile Y Type Strainer (20K) (Screwed Type)
#Grup produk P103048035
Sebelum PPN:
Rp1.499.900 - Rp5.099.900
Ketersediaan:
Periksa Metode Pembayaran dan Estimasi pengiriman
Spesifikasi
| Material (plug) | SUS304 |
|---|---|
| Material (washer) | SS400 |
| Body Material | FCD-S |
| Connection Method | The screw-shaped |
| Cover Material | FCD-S |
| Fluid Used | Water, oil, air, steam, gas |
| Handle Shape | Without handle |
| Material | [Cover bolt] S45C |
| Material (Gasket) | Non-asbestos sheet gasket |
| Material (screen) | SUS304 (40 mesh, wire Across (SUS304 punch plate reinforcement) |
| Maximum Working Pressure (MPa) | 2.75 (-10°C - +120°C electrostatic running water), 2.45 (-10°C - +220°C steam, air, gas, oil, pulsating water), 2.4 (-5°C - +220°C, gas) (when the high-pressure gas safet |
| Shape | Y-shaped |
| Type | strainer |
Pilih jenis produk yang diinginkan
| Nomor SKU | Model Number | Masa Persiapan Barang | Harga | Jumlah |
|---|---|---|---|---|
| Loading... | ||||
Apakah produk dengan spesifikasi yang Anda inginkan belum tersedia? Hubungi tim Layanan Pelanggan kami di sini
Informasi Produk
Warning
- When applying the High Pressure Gas Safety Act, the air and gas will be 2.4MPa (-5°C to +220°C). - When used beyond 260°C, it is necessary to change the material of the gasket, so please check separately.
