JST Two-Hole Type Terminal (NTT Type)
#Grup produk P102907315
Spesifikasi
| Compatible Tool | Manual: - _ x000 D_, pneumatic type: YA - 4 YA - 5 YAT - 4 A YAD - 4 A _ x 000 D _, hydraulic type: YPT - 60 N YPT - 150 - 1 BCT - 0514 BCT - 860 N BCT - 8150 (main body) YF - 1 E - 4 (Head) YET-60-1 YET-150-1 |
|---|---|
| Dimension F (mm) | 14.5 |
| Dimensions a (mm) | 16 |
| Conjugation Wire Range (single)(mm) | 3.65 to 4.62 |
| Dimension K (mm) | 7 |
| Dimension d1(phi mm) | 5.8 |
| Dimensions d (mm) | Φ9 |
| Dimensions d2 (mm) | 6.4 phi |
| Dimensions e (mm) | 10.5 |
| Dimensions t (mm) | 1.5 |
| Electric AWG Wire Conjugation Range (#) | 6 |
| Overall Length (mm) | 48 |
| Terminal Shape | Plate shape |
| Type | Bare crimp terminal |
| Width (mm) | 15 |
| Wire Conjugation Range Stranded (mm²) | 10.52 to 16.78 |
Pilih jenis produk yang diinginkan
| Nomor SKU | Model Number | Masa Persiapan Barang | Harga | Jumlah |
|---|---|---|---|---|
| Loading... | ||||
Apakah produk dengan spesifikasi yang Anda inginkan belum tersedia? Hubungi tim Layanan Pelanggan kami di sini
Informasi Produk
Description
Compatible Tool (Hydraulic Type): YPT-60NYPT-150-1BCT-0514BCT-860NBCT-8150 (MainBody) YF-1E-4 (Head) YET-60-1YET-150-1
