JST Connector for Printed Circuit Board ZH Series
#Grup produk P102904293
Spesifikasi
| Electric AWG Wire Conjugation Range (#) | 28 - 26 |
|---|---|
| Material | Phosphor bronze |
| Rated Current (A) | 1.0 AC, DC (when using AWG # 26) |
| Rated Voltage (V) | 50 AC, DC |
| RoHS Directive | Correspondence |
| Contact Resistance (miliΩ) | Initial / 20 or less, after environmental test / 30 or less |
| Electric Wire Covering Outer Diameter (mm) | 0.8 to 1.1 |
| Insulation Resistance (MΩ) | 500 or more |
| Operating Temperature Range (°C) | -25 to + 85 (Including the temperature rise value during energization) |
| Surface Processing | Tin plating (reflow processing) |
| Wire Conjugation Range (mm²) | 0.08 to 0.13 |
| Withstand Voltage | AC 500 V, 1 minute |
Pilih jenis produk yang diinginkan
| Nomor SKU | Model Number | Masa Persiapan Barang | Harga | Jumlah |
|---|---|---|---|---|
| Loading... | ||||
Apakah produk dengan spesifikasi yang Anda inginkan belum tersedia? Hubungi tim Layanan Pelanggan kami di sini
Informasi Produk
Feature
Compact, Low Profile Market Space Design. Housing Lance System. Stable Contact Structure. Strong Mating Structure for Snag. Mating with Pressure Welding ZR Connector.Operating Temperature Range -25 to +85°C (Including The Temperature Rise ValueUlasan Produk
