SUPER TOOL U-Shaped Groove Clamp
#Grup produk P102553239
Spesifikasi
| Clamp Range | 30 to 60mm |
|---|---|
| Dimensions h1 | 108mm |
| Dimensions h2 | 83mm |
| Capacity | 0.15t |
| Dimension B | 185mm |
| Dimension B2 | 65mm |
| Dimension B3 | 55mm |
| Dimension D1 | 50mm |
| Dimension D2 | 70mm |
| Dimension L | 258-332mm |
| Dimension T | 44.5mm |
| Dimension T1 | 31mm |
| Dimensions b1 | 65mm |
| Dimensions h | 200mm |
| TRUSCO Number | 104-2106 |
Pilih jenis produk yang diinginkan
| Nomor SKU | Model Number | Masa Persiapan Barang | Harga | Jumlah |
|---|---|---|---|---|
| Loading... | ||||
Apakah produk dengan spesifikasi yang Anda inginkan belum tersedia? Hubungi tim Layanan Pelanggan kami di sini
Informasi Produk
Description
Ideal for machine, U-shaped, U-shaped flume, L-shaped panel, shelf board and so on.(Urethane pad type). Damage protection of concrete and products by pad type of urethane rubber. Switching to release lock is easy with one touch operation of hook plate.Mechanism that the grip force increases more strongly in proportion to the lifting load. Intact type
Warning
* Please be sure to strictly observe two or more hanging in safety. Do not lift objects of the size and dimensions outside the clamping range. Please do not use other than reinforced concrete hanging. It can not be used for curing concrete products. Never do a way of hanging such as lateral grips, cams and pads touching the grips of the U-shaped groove.Please be careful about the position of the center of gravity of the lifting object and lift it so as not to be transversely shifted.Ulasan Produk
