Be used for general air pressure piping, it is a compact one-touch fittings. It has been volume ratio of 40% smaller than that of the standard.
. Large selection of models, correspond to any air pressure piping. After installation, you can change the take-off angle of the tube.
. (Limited to the combination products of the connection port shape/screw and push-in joint.) Sealing material is Yes in advance application. Therefore, the sealing tape is not required.
Useable: Connection of the screw and tube
PISCO Mini Type Female Straight
#Grup produk P102534553
Spesifikasi
| Material | Open ring/POM, resin body/PBT |
|---|---|
| Shape | Female straight |
| Type | Mini type |
| Operating Temperature Range | 0 to 60°C (without freezing) |
| Connection Screw Type | M |
| Dimension A (mm) | 4.5 |
| Dimension P | 8mm |
| Fluid | air |
| Maximum Working Pressure | 1MPa |
| Opposite Side H | 8mm |
| Vacuum Pressure | -100kPa |
