OMRON RFID System Tag Battery Less Type V680 Series
#Grup produk P102415416
Spesifikasi
| Data Retention | 10 years after writing data (85 ° C or less) |
|---|---|
| Vibration Resistance | 10 to 2000Hz Double amplitude 1.5mm Acceleration 150m/s2 , XYZ directions 15 minutes each for 10 minutes, no abnormalities |
| Heat Resistance | Thermal cycle -10/+150°C 30 minutes each 1000 cycles, high temperature storage +150°C 1000 hours Thermal cycle -10/+180°C 30 minutes each 200 cycles, high temperature storage +180°C 200 hours |
| Protection Class | IP68 (IEC60529 standard), oil resistant IP67G equivalent (JIS C 0920: 2003 Annex 1) |
| Ambient Relative Humidity (RH) | 35 to 95 |
| Material (Molding) | PPS resin |
| Memory Capacity | 1000 bytes (user area) |
| Metal Compatible | Metal mounting |
| Number of Rewritings | Data / 100,000 times per block (25 ° C) |
| Operating Ambient Temperature (°C) | Communication / -25 to +85 (no freezing) |
| Shape Size (mm) | 34x34x3.5 |
| Shock Resistance (m/s2) | Apply 500 impacts in each direction of X, Y, Z 3 times each 18 times in total |
| Storage Temperature (°C) | Data retention / -40 to +125 (no freezing) |
| Type | Memory / EEPROM |
Pilih jenis produk yang diinginkan
| Nomor SKU | Model Number | Masa Persiapan Barang | Harga | Jumlah |
|---|---|---|---|---|
| Loading... | ||||
Apakah produk dengan spesifikasi yang Anda inginkan belum tersedia? Hubungi tim Layanan Pelanggan kami di sini
Informasi Produk
Feature
- High-speed communications and highly reliable communications provided with an electromagnetic induction system and unique technology.- Antennas and RF Tags with excellent environmental resistance.- Wide line-up of ultra-compact, long-life RF TUlasan Produk
