OMRON Digital, Time Switch
#Grup produk P102415160
Sebelum PPN:
Rp4.599.900 - Rp4.899.900
Ketersediaan:
Periksa Metode Pembayaran dan Estimasi pengiriman
Spesifikasi
| Setting Value | Minimum unit: 1min unit |
|---|---|
| Power Consumption | Approximately 2.9VA (at AC264V) |
| Ambient Relative Humidity (RH) | 25 to 85 |
| Type | 2ch / week |
| Case Color | Light gray (Munsell 5Y7 / 1) |
| Accuracy | (Clock) Standard |
| Control Output | Number of circuits: 2 independent circuits (2a)<br> Circuit: Power supply circuit and separate circuit (no voltage)<br> Capacity: Resistance not possible AC250V 15A (cosΦ=1), induction not possible AC250V 10A (cosΦ=0.7) |
| Family Type | H5S |
| Impact Resistance Durability (m/s²) | 300 3 axes 6 directions 3 times each |
| Influence of Voltage | ± 0.01% ± 0.05s or less ± 0.01% is the value for the set time interval |
| Insulation Resistance (MΩ) | 100 or more Between conductive part terminals and exposed non-charged metal parts, between operation power supply circuit and control output, between control outputs, between non-continuous contacts |
| Operating Ambient Temperature (°C) | -10 to +55 (with no icing or condensation) |
| Power Supply Voltage (V) | AC100-240 (50 / 60Hz shared) |
| Time | 1 cycle: 1 week (7 days) |
| Type of Operation | Digital quartz system |
| Vibration Resistance (Destruction) | 10 to 55Hz, single amplitude 0.375mm, 3 directions, 2ch each |
Pilih jenis produk yang diinginkan
| Nomor SKU | Model Number | Masa Persiapan Barang | Harga | Jumlah |
|---|---|---|---|---|
| Loading... | ||||
Apakah produk dengan spesifikasi yang Anda inginkan belum tersedia? Hubungi tim Layanan Pelanggan kami di sini
Informasi Produk
Feature
- Independent Day Keys provide easier operation. - Temporary holiday setting function makes it easy to turn OFF output for holidays and non-operating days. - Settings can be made even with the Time Switch turned OFF. - Test mode enables easy proUlasan Produk
