OMRON Sysmac CJ Series Input Unit
#Grup produk P102414356
Spesifikasi
| Voltage (V) | (ON) DC 14.4 or more, (OFF) DC 5 or less |
|---|---|
| Number of Input Points | (I / O) 16 points (high speed) |
| Insulation Resistance (MΩ) | 20 / between external terminals and GR terminal (at 100 VDC) |
| Applicable Standard | cULus (Class I Div2 Hazardous Location Certified Product), NK, Lloyd, EC Directive |
| Series | CJ1 |
| Common Specifications | 16 points, 1 common |
| Allowable Voltage Range (V) | DC20.4 to 26.4 |
| Current (mA) | (ON) 3 or more, (OFF) 1 or less |
| Current Consumption (A) | 5V system / 0.13 |
| Input Current (mA) | 7 |
| Input Impedance (ohm) | 3.3k |
| Input Method | DC |
| Input Voltage (V) | DC24 |
| Number of Circuits | 16 points (16 points / common 1 circuit) |
| Response Time | (ON / OFF) 8.0ms or less (0 to 32ms can be switched depending on the setting) ・ (When 0ms is set, the ON response time is 15μs or less due to the delay of the internal element. The OFF response time is 90μs or less.) |
| Type | DC24V input unit |
| Withstand Voltage | 1000V AC for 1 minute between external terminals and GR terminal Leakage current 10mA or less |
Pilih jenis produk yang diinginkan
| Nomor SKU | Model Number | Masa Persiapan Barang | Harga | Jumlah |
|---|---|---|---|---|
| Loading... | ||||
Apakah produk dengan spesifikasi yang Anda inginkan belum tersedia? Hubungi tim Layanan Pelanggan kami di sini
Informasi Produk
Description
Number of Circuits: 16 (16 points/common, 1 circuit).
