Wide Range of Locking-type
Models Available
- Character height of 4.8 or 3.2 mm makes for easy-toview
display.
- Installation is easy with snap-in mounting.
- The series includes a complete range of locking-type models that prevent accidental operation.
Character Height: Decimal: 4.8mm Hexadecimal: 3.2mm.
OMRON Thumb Rotary Switch A7BS/A 7 BL
#Grup produk P102414240
Spesifikasi
| Type of Sign | One-touch mounting (surface mounting) |
|---|---|
| Ambient Relative Humidity (RH) | 45 to 85 |
| AS ONE Part Number | 64-3337-82 |
| Shock Resistance (m/s2) | 490 or more |
| Case Color | Black |
| Vibration Resistance | 10~55Hz double amplitude 1.5mm |
| Character Height (mm) | 4.8 |
| Color (Body) | Black |
| Contact Resistance (miliΩ) | 300 or less |
| Continuous Current (A) | Up to 1 |
| Electrical Durability (steps) | More than 50,000 |
| Insulation Resistance (MΩ) | Between terminals of the same polarity: 10 or more (at DC500V megger) Between each terminal and ground: 1000 or more (at DC500V megger) |
| Load Capacity | (Open / close load) 1mA-0.1A, AC50V / DC3.3-28V (resistive load) |
| Mechanical Durability | 100,000 steps or more |
| Operating Ambient Temperature (°C) | -10 to +65 (no icing) |
| Operating Force (N) | 5.39 or less |
| Type of Output Code | 06 (binary decimal) |
| Type of Terminal | Solder terminal |
| Withstand Voltage | Between terminals of the same polarity: AC600V 50/60Hz for 1min Between each terminal and ground: AC1000V 50/60Hz for 1min |
