- Separate type round cylinder type Φ 16 series.
- Shorter body size of industry minimum class 28.5mm.
- Switch unit can be attached/detached.
- Shared contacts that can be used for both general load and micro load.
- Terminal arrangement considering ease of wiring.
- EN 60947-5-1 certification.
- Withstand voltage Between same pole terminals and between lamp terminals: AC 1000 V 50/60 Hz 1 min / Different pole terminals, between terminals and ground: AC 2.000V 50/60Hz 1 min.
- Storage Temperature: -25 to +65°C (with no freezing or condensation).
OMRON Pushbutton Switches (Rectangle) (Led) (Round Body Type 16)
#Grup produk P102414213
Spesifikasi
| Terminal Shape | Solder terminal |
|---|---|
| Withstand Voltage | Between homopolar terminals, between lamp terminals: 1000 VAC 50/60 Hz for 1 min / between different polarity terminals, between each terminal and ground: 2000 VAC 50/60 Hz for 1 min |
| Ambient Relative Humidity (RH) | 35 to 85 |
| Applicable Voltage (V) | AC/DC24 |
| Type of Operation | Momentary |
| Allowable Operation Frequency | Mechanical: 120 times / min max., Electrical: 20 times / min |
| Button Shape | Long angle (2-way guard) |
| Contact Configuration | 2c |
| Electric Shock Protection Class | Class II |
| Electrical Durability | 100,000 times or more |
| Impact Resistance Durability (m/s²) | 500 |
| Insulation Resistance (MΩ) | 100 or more (with DC500V mega) |
| Light Source | LED |
| Mechanical Durability | 2 million times or more |
| Operating Ambient Temperature (°C) | -10 to +55 (with no icing or condensation) |
| Protection Class | IP40 |
| Shock Resistance Malfunction (m/s²) | Up to 150 (within malfunction 1ms) |
| Storage Temperature (°C) | -25 to +65 (with no icing or condensation) |
| Type | Illuminated |
| Vibration Resistance (Malfunction) | 10 to 55Hz, double amplitude 1.5mm (malfunction 1ms) |
