Ambient temperature
At use: -10 to +55°C When saving: -25 to +80°C (do not freeze)
Output capacity
Applied voltage: DC 28 V or less
Sink current: 16 mA or less
Residual voltage: 0.4 V or less (at sink current 16 mA).
Direction of Rotation: Increase output code at CW (right rotation as seen from the shaft side).
OMRON Encoder E6CP Type
#Grup produk P102413667
Sebelum PPN:
Rp2.899.900 - Rp3.099.900
Ketersediaan:
Periksa Metode Pembayaran dan Estimasi pengiriman
Spesifikasi
| Type | Rotary encoder |
|---|---|
| Family Type | E6CP-A |
| Resolution | 256 pulses/revolution |
| Case Material | ABS |
| Protective Structure | IEC standard IP 50 |
| Cord Length (m) | 2 |
| Main Body Material | Polyphenylene sulfide |
| Material (Mounting Bracket) | Iron zinc plating |
| Maximum Response Frequency (kHz) | 5 |
| Shaft Material | SUS 416 |
