OMRON Power, solid state, relay G3PA
#Grup produk P102371334
Spesifikasi
| Suitable Load of Output | 30A AC200 to 480V |
|---|---|
| Return Voltage | DC1V or more |
| Ambient Relative Humidity (RH) | 45 to 85 |
| Equipped with / without Zero Cross Function | Included |
| Standard | UL508, CSA22.2 No.14, EN60947-4-3 |
| Insulation Resistance (MΩ) | 100 or more (with DC500V mega) |
| Type of Insulation | Photo triac coupler |
| Leakage Current (mA) | 20 or less (at 480 VAC) |
| Load voltage (V) | AC180 to 528(50/60Hz) |
| Operating Ambient Temperature (°C) | -30 to 80 (with no icing or condensation) |
| Operating Time (ms) | 1/2 cycle of load power supply + 1 or less |
| Operating Voltage (V) | DC9.6 or less |
| Operating Voltage Range (V) | DC9.6 to 30 |
| Rated Load Voltage (V) | AC200 to 480(50/60Hz) |
| Rated Voltage (V) | DC12 to 24 |
| Shock Resistance (m/s2) | 300 (DIN rail mounting) |
| Storage Temperature Range (°C) | -30 to +100 (with no icing or condensation) |
| Type | Solid state/relay |
| Voltage Drop When Output Turned On (V) | 1.8 (RMS) or less |
Pilih jenis produk yang diinginkan
| Nomor SKU | Model Number | Masa Persiapan Barang | Harga | Jumlah |
|---|---|---|---|---|
| Loading... | ||||
Apakah produk dengan spesifikasi yang Anda inginkan belum tersedia? Hubungi tim Layanan Pelanggan kami di sini
Informasi Produk
Description
Ultracompact slim type with integral heat sink. . As well as screw mounting, DIN rail installation is also possible. .Easy attachment and attachment with connecting terminals, applicable to three-phase loading. . Even if the power element is destroyed, it is possible to replace the power element with a cartridge system. . EN, IEC, VDE, UL, CSA standards acquired.
