OMRON Programmable controller CJ1/CJ1M I/O unit
#Grup produk P102371015
Sebelum PPN:
Rp5.699.900 - Rp9.099.900
Ketersediaan:
Periksa Metode Pembayaran dan Estimasi pengiriman
Spesifikasi
| Applicable Standard | cULus (Class I Div 2 hazardous area certified product), NK, EC directive |
|---|---|
| Current (mA) | (Input part) ON current / 3 or more, OFF current / 1 or less |
| Unit Type | CJ1 basic I / O unit |
| Fuse | None |
| Input Voltage Tolerance (V) | DC20.4 to 26.4 |
| Inrush Current (A/ms) | (Maximum) 3.0 / point 10 or less |
| Insulation Resistance (MΩ) | Between external terminals and GR terminal / 20 (at 100 VDC) |
| Leakage Current (mA) | 0.1 or less |
| Load voltage (V) | (Output) DC 10.2 to 26.4 |
| Rated Input Voltage (V) | DC24 |
| Rated Output Voltage (V) | DC12 to 24 |
| Type | DC input / transistor output unit (sink type) |
Pilih jenis produk yang diinginkan
| Nomor SKU | Model Number | Masa Persiapan Barang | Harga | Jumlah |
|---|---|---|---|---|
| Loading... | ||||
Apakah produk dengan spesifikasi yang Anda inginkan belum tersedia? Hubungi tim Layanan Pelanggan kami di sini
Informasi Produk
Description
Two types of interfaces, Fujitsu Connector and MIL Connector, can be used separately. .Sink type and source type can be selected on the output side. CJ1W - MD232 is equipped with load short circuit protection function. . ON, OFF Response time can be switched from 0 to 32 ms by PC system setting of CPU unit. . 5 VTTL input / output unit (CJ 1 W - MD 563) is also available. .Various types of terminal block conversion units are available.Wiring with external input / output equipment is also easy.
