OMRON Programmable controller L type I/O 14 points
#Grup produk P102370131
Spesifikasi
| Suitable CPU | Memory capacity/5K step high-speed counter/100kHz 4 axes |
|---|---|
| Power Supply | AC power supply |
| Applicable Standard | cULus (Class I Div2 Hazardous Location Certified Product), NK, Lloyd, EC Directive |
| Clock Function | Yes Accuracy/monthly difference -4.5 minutes to -0.5 minutes (ambient temperature 55°C), -2.0 minutes to +2.0 minutes (ambient temperature 25°C), -2.5 minutes to +1.5 minutes (ambient temperature 0°C) |
| Pulse Output | PWM output: Duty ratio 0.0 to 100.0% variable (specified in units of 0.1% or 1%), 2 points 0.1 to 6553.5Hz or 1 to 32800Hz (accuracy +1%/-0%: 0.1 to 10000Hz, +5%/ -0%: 10000 to 32800Hz) |
| Command | Word length: 1 to 7 steps/1 instruction Types: Approx. 500 types (FUN No. is 3 digits) |
| Type | USB port type |
| Communication Function | Built-in peripheral port (USB1.1) x 1: Support software connection only. Up to 1 serial communication option board can be installed. Up to 1 Ethernet communication option board can be installed. |
| Data Memory | 10K words D0 to D9999, D32000 to D32767 |
| Function | Maximum number of function block definitions: 128, maximum number of instances: 256 Languages that can be used in function block definitions: ladder chart, structured text (ST) |
| In / Out control method | Combined use of cyclic scan and processing method |
| Memory | Trace memory / 4000 words |
| Memory Backup | Flash memory/user programs, parameters (PC system settings, etc.), comment information, all data memory areas can be saved in flash memory (data memory initial values) Battery backup/retention relays, data memory, counters (flags and current values) |
| Number of Input/Output Points | 8 inputs, 6 outputs |
| Number of tasks | 288 (cycle execution task 32, interrupt task 256) |
| Programming language | Ladder chart method |
| Register points | Data register/16 points (16 bits) DR0 to DR15 Index register/16 points (32 bits) IR0 to IR15 |
| Timer / counter | 4096 points (T0 to T4095) / 4096 points (C0 to C4095) |
| Type of control | Stored program method |
