OMRON Proximity sensor flat type TL-W
#Grup produk P102369320
Sebelum PPN:
Rp1.099.900 - Rp1.599.900
Ketersediaan:
Periksa Metode Pembayaran dan Estimasi pengiriman
Spesifikasi
| Ambient Humidity (% RH) | Operating and storage: 35 to 95 each (no condensation) |
|---|---|
| Cable Length (m) | 2 |
| Influence of Temperature | ± 10% or less of detection distance at + 23 ° C within the temperature range of -25 to + 70 ° C |
| Influence of Voltage | ± 2.5% or less of sensing distance at rated power supply voltage within the range of rated power supply voltage ± 10% |
| Insulation Resistance (MΩ) | 50 or more (at 500 VDC) between live parts and case |
| Operating Voltage Range (V) | DC10 to 30 |
| Output | DC 3-wire NPN |
| Protection Class | IEC standard IP67, company standard Oil resistant |
| Protection circuit | Reverse connection protection, surge absorption |
| Type of Connection | Cord drawer type |
| Vibration Resistance (Durability) | 10~55 Hz, 1.5 mm double amplitude, 2 hours each in X, Y, and Z directions |
Pilih jenis produk yang diinginkan
| Nomor SKU | Model Number | Masa Persiapan Barang | Harga | Jumlah |
|---|---|---|---|---|
| Loading... | ||||
Apakah produk dengan spesifikasi yang Anda inginkan belum tersedia? Hubungi tim Layanan Pelanggan kami di sini
Informasi Produk
Description
Flat type standard with abundant variation. Thickness 6 mm and detection distance 3 mm (TL - W 3 MC 1). Series of aluminum die casting type
