OMRON Cam Positioner Body 3 F 88 L-160/162
#Grup produk P102367854
Spesifikasi
| Product Code | 3F88L-162 |
|---|---|
| Operating Ambient Temperature (°C) | 0 to +55 |
| Shock Resistance (m/s2) | 147 3 times in each direction of X, Y, Z |
| Allowable Voltage Range (V) | AC85 to 264 |
| usage environment | Free of corrosive gases |
| Ambient Humidity (%) | 10-90 (no condensation) |
| Allowable Instantaneous Power Outage Time (ms) | 15 or less does not detect momentary power outage |
| Control Unit | 1/360 (at resolution 360), 1/720 (at resolution 720) |
| Control specifications | Input /START, TRIG, BANK1~3, RESET, photocoupler input Input impedance 4.7kΩ Output /RUN, ERROR, M・DET, open collector power Maximum switching capacity DC26.4V 300mA |
| Correction Function | Origin correction/1 to 359 (at resolution 360), 1 to 719 (at resolution 720)\nBacklash correction/1 to 179 (at resolution 360), 1 to 359 (at resolution 720)\nLead angle correction/Lead angle amount input range : 1 to 359 (at resolution 360), 1 to 719 (at resolution 720), Speed input range: 1 to 1600 (at resolution 360), 1 to 800 (at resolution 720) |
| Display Method | 7 segment LED (execution bank, rotation speed, current angle) |
| External Dimensions (mm) | 110x100x82.5 |
| Family Type | 3F88L |
| Inrush Current (A) | 40/10ms or less |
| Installation Method | M4 screws (2 points) or DIN rail mounting |
| Insulation Resistance (MΩ) | Between all power supply AC external terminals and protective earth terminal: 20 or more (DC500V mega) |
| Noise resistance | 2kV (power line) Compliant with IEC61000-4-4 |
| Number Of Output Points | 32 points |
| Number of Banks | 8 banks (at resolution 360), 4 banks (at resolution 720) |
| Output | Open collector output maximum switching capacity DC26.4V300mA (1.6A or less per connector) |
| Power Consumption (V/A) | 27 or less |
| Power Supply Voltage (V) | AC100 to 240 |
| Protection Function | Memory: Non-volatile memory (EEP-ROM) written 100,000 times |
| Reproducibility (°) | 0.2 |
| Response Rotation Speed (rpm) | 1600 (at resolution 360), 800 (at resolution 720) |
| Storage Temperature Range (°C) | -20 to +75 |
| Structure | Built-in panel type |
| Terminal screw | Power input section: M3.5, control input/output section: M3 |
| Vibration Resistance | 10~57Hz amplitude 0.075mm, 57~150Hz acceleration 9.8m/s 2 80 minutes each in X, Y, Z directions (8 minutes sweep x 10 sweeps = total 80 minutes) |
| Withstand Voltage | Between all power supply AC external terminals and protective earth terminal: AC2, 300V 50/60Hz for 1 minute (leakage current 10mA or less) |
Pilih jenis produk yang diinginkan
| Nomor SKU | Model Number | Masa Persiapan Barang | Harga | Jumlah |
|---|---|---|---|---|
| Loading... | ||||
Apakah produk dengan spesifikasi yang Anda inginkan belum tersedia? Hubungi tim Layanan Pelanggan kami di sini
Informasi Produk
Description
Compact design contributes to space saving.With easy operation, setting, cam output according to rotation angle is possible.Acquisition of UL / CSA, conformity with EC directive, support global response.Equipped with abundant functions that can be used on site
