OMRON Small limit switch D4C-
#Grup produk P102367094
Spesifikasi
| Vibration Resistance (Malfunction) | 10-55Hz Double vibration line 1.5mm |
|---|---|
| Protection Class | IP67 |
| Ambient Relative Humidity (RH) | 35-95 or less |
| Type | Compact limit switch |
| Electrical Durability | 200,000 operations or more (125 VAC, 5 A resistance load) |
| Impact Resistance Durability (m/s²) | 1000 or more |
| Insulation Resistance (MΩ) | 100 or more (with DC500V mega) |
| Mechanical Durability | 10 million times or more |
| Operating Ambient Temperature (°C) | -10 to 70 (no icing) |
| Rated Frequency (Hz) | 50/60 |
| Rated Insulation Voltage (V) | (Ui)300(EN60947-5-1) |
| Shock Resistance Malfunction (m/s²) | 500 or more |
| Withstand Voltage | (Between terminals of the same polarity) AC1000V 50/60Hz 1min, (Between live metal parts and ground) AC1500V 50/60Hz 1min/Uimp 2.5kV (EN60947-5-1), (Between each terminal and non-chargeable metal parts) AC1500V 50/ 60Hz 1min/Uimp 2.5kV (EN60947-5-1) |
Pilih jenis produk yang diinginkan
| Nomor SKU | Model Number | Masa Persiapan Barang | Harga | Jumlah |
|---|---|---|---|---|
| Loading... | ||||
Apakah produk dengan spesifikasi yang Anda inginkan belum tersedia? Hubungi tim Layanan Pelanggan kami di sini
Informasi Produk
Description
Small size, thin shape, small size limit switch boasting high sealability. EN, UL, CSA, CCC standards acquired. . High sealability conforming to IP 67 of IEC. . The plunger part is a seal packing, a diaphragm, a built-in switch part is a protective cap and a triple seal structure. . 3 m, 5 m code as standard.
