OMRON CJ Series DeviceNet Unit
#Grup produk P102365980
Spesifikasi
| Protocol | (Communication) DeviceNet compliant |
|---|---|
| Ambient Relative Humidity (RH) | 10 to 90 (no condensation) |
| Applicable Standard | cULus (Class I Div 2 Hazardous Location Certified Product), NK, Lloyd, EC Directive |
| Atmosphere | No corrosive gas |
| Suitable For | (Controller) CJ / NJ series |
| Communication Conditions | Maximum message length / 542 bytes (including command code when using CMND instruction (SendCmd instruction for NJ series)) |
| Communication Method | Remote I / O communication master (fixed or free assignment), remote I / O communication slave (fixed or free assignment), message communication |
| Communication Speed (bit/s) | 500k / 250k / 125k |
| Control | Multi-drop method and T-branch method can be combined (for main line and support) (Terminal resistors are required at both ends of main line) |
| Current Consumption (A) | 5V system: 0.29 |
| Family Type | CJ1W |
| Maximum number of connections | Slave / 63 units (Remote I / O, Explicit message service) |
| Noise resistance | Compliant with IEC61000-4-4 2kV (power line) |
| Operating Ambient Temperature (°C) | 0 to +55 |
| Power Supply (V DC) | 24 supplied from communication / external |
| Power Supply Voltage (V) | (Communication) DC11-25 |
| Product Code | CJ1W0282R |
| Storage Temperature (°C) | -20 to +75 (excluding battery) |
| Vibration Resistance | Compliant with JIS C0040 10 to 57Hz, amplitude 0.075mm, 57 to 150Hz, acceleration 9.8m/s2 80 minutes in each of X, Y, and Z directions (8 minutes sweep time x 10 sweeps = 80 minutes total) |
Pilih jenis produk yang diinginkan
| Nomor SKU | Model Number | Masa Persiapan Barang | Harga | Jumlah |
|---|---|---|---|---|
| Loading... | ||||
Apakah produk dengan spesifikasi yang Anda inginkan belum tersedia? Hubungi tim Layanan Pelanggan kami di sini
Informasi Produk
Description
Industry's smallest! DeviceNet unit compatible with CJ series equipped with industry's top class performance and features! Up to 32000 points (2000 CH) / master control is realized, simultaneity of data is guaranteed. .Master and slave functions are insta
