OMRON SYSMAC CJ series CJ2M pulse I/O unit
#Grup produk P102365236
Sebelum PPN:
Rp4.099.900 - Rp5.599.900
Ketersediaan:
Periksa Metode Pembayaran dan Estimasi pengiriman
Spesifikasi
| Leakage Current (mA) | 0.1 or less |
|---|---|
| Pulse Output | Relative coordinate specification/00000000 to 7FFFFFFFHex (addition/subtraction each direction: 2147483647) Absolute coordinate specification/80000000 to 7FFFFFFFHex (-2147483648 to 2147483647) |
| Number of Outputs | Pulse output/maximum 4 points (pulse output 0 to 3) PWM output/maximum 4 points (PWM output 0 to 3) |
| Applicable Standard | cULus (Class I Div2 hazardous area certified product), NK, Lloyd, EC Directive |
| Output Frequency (Hz) | Pulse output / up to 100k, PWM output / up to 32800 |
| Detection Method | (Interrupt) Falling / rising |
| Type of control | (High-speed counter) Target value match comparison/register up to 48 target values and interrupt task numbers Bandwidth comparison/register up to 8 or 32 upper/lower limit values and interrupt task numbers |
| Duty Ratio | Variable duty ratio pulse output (PWM) function / 0.0 to 100.0% (set in units of 0.1%) |
| Frequency Range | Pulse output / 1pps ~ 100kpps (1pps unit) 2 points x 2 units PWM output / 0.1Hz ~ 6553.5Hz (set in 0.1Hz units) or 1Hz ~ 32800Hz (set in 1Hz units) |
| Input Method | High-speed counter input count mode / addition pulse input, phase difference input (multiplication by 4), addition / subtraction pulse input, pulse + direction input |
| Input Signal | (High-speed counter input) Addition pulse input/addition pulse, phase difference input (multiplied by 4)/A phase/B phase/Z phase, addition/subtraction pulse input/addition pulse/subtraction pulse/reset, pulse + direction input/pulse/direction/ reset |
| Input Voltage (V) | (ON) DC 1.74 or more, (OFF) DC 5 or less |
| Number of Input Points | Interrupt input/up to 8 points Pulse catch/up to 8 points (30 μs, which is shorter than the cycle time, can be captured as one cycle ON signal) High-speed counter/up to 4 points (high-speed counter 0 to 3) |
| Operating Voltage Range (V) | (Output load) DC 4.75 to 26.4 |
| Output Type | (Pulse output) CW / CCW, pulse + direction |
| Response Time | Output ON/OFF: 0.1ms or less Input ON/OFF: 8ms or less (0/0.5/1/2/4/8/16/32ms switchable by PLC system setting) Interrupt input/pulse catch input: (ON) 30μs Below, (OFF) 150μs or less |
| Voltage (V) | Residual / 0.6 or less |
