OMRON Power relay G6B
#Grup produk P102364796
Spesifikasi
| Terminal Shape | Printed circuit board terminal |
|---|---|
| Protection Class | Plastic seal type |
| Ambient Relative Humidity (RH) | 5 to 85 |
| Classification | Standard type |
| Return Voltage | More than 10 |
| Coil Rated Voltage (V) | DC24 |
| Type of Terminal Fitting | Dedicated type for PCB mounting |
| Contact Configuration | 1a |
| Contact Resistance (miliΩ) | 30 or less (DC5V 1A voltage drop method) |
| Function | Single stable type |
| Impact Resistance Durability (m/s²) | 1000 |
| Insulation Resistance (MΩ) | 1000 or more (DC500V) |
| Number of Poles | 1 pole |
| Operating Ambient Temperature (°C) | -25 to +70 (with no icing or condensation) |
| Power Consumption (mW) | About 200 |
| Rated Voltage (V) | DC24 |
| Standard | UL, CSA standard certified standard product |
| Type | Power relay |
| Vibration Resistance (Destruction) | 10~55~10 Hz, single amplitude 0.75 mm (double amplitude 1.5 mm) |
Pilih jenis produk yang diinginkan
| Nomor SKU | Model Number | Masa Persiapan Barang | Harga | Jumlah |
|---|---|---|---|---|
| Loading... | ||||
Apakah produk dengan spesifikasi yang Anda inginkan belum tersedia? Hubungi tim Layanan Pelanggan kami di sini
Informasi Produk
Description
High capacity, high pressure resistance, sealed structure, compact power, type. The withstand voltage is high insulation with AC 3000 V (impact resistance voltage 6 kV) between coil and contact.Considering the correspondence to the automated line, we also offer stick packaging.Acquired UL 508, CSA standard in standard form.
