OMRON Programmable controller CS series Analog input/output unit
#Grup produk P102363441
Sebelum PPN:
Rp15.999.900 - Rp22.999.900
Ketersediaan:
Periksa Metode Pembayaran dan Estimasi pengiriman
Spesifikasi
| Resolution | 1/8000 (can also be set to 1/4000) |
|---|---|
| Number of Occupied Units | Number of occupied units: Unit 1 (Units No. 0 to 95) |
| Applicable Standard | cULus (Class Div 2 hazardous area certified product), NK, Lloyd, EC directive |
| Type of Insulation | Non-isolated between inputs |
| Conversion Speed (μs) | 250 /point or less (can also be set to 1 ms / point) |
| Ambient Relative Humidity (RH) | 10 to 90 (no condensation) |
| Current Consumption (A) | (5V) 0.12, (26V) 0.09 |
| External Connection | Detachable terminal block |
| Insulation Resistance (MΩ) | Between insulation parts / 20 or more (DC500V) |
| Mounting Position | CPU device for CS series or expansion device for CS series |
| Operating Ambient Temperature (°C) | 0 to 55 |
| Self-Diagnosis Function | Diagnostic results are displayed with LEDs |
| Unit Type | CS1 advanced I / O unit |
| Withstand Voltage (V/minute) | Between insulation parts AC1000 |
