OMRON Slim-styled I/O Relay
#Grup produk P102127001
Spesifikasi
| Item Code | G7T 3010C |
|---|---|
| Ambient Humidity (%RH) | 5 to 85 |
| Case Color | transparent |
| Coil Rated Voltage (V) | DC24 |
| Contact Configuration | 1a |
| Contact Material | AgSnIn |
| Contact Rated Control Capacity (V-A) | DC24-1/AC110-1 (for input), DC24V 5A/AC220V 2A (for output) (resistive load) |
| Contact Resistance (miliΩ) | 50 or less (based on voltage drop method with DC5V 1A current) |
| Electrical Durability | 1 million times (at rated load) (ambient temperature +23℃) |
| Failure Rate P Level (V-mA) | DC5-10 (reference value: when opening/closing frequency is 120 times/min) |
| Inductive Load (V-A) | DC24-2, AC220-1 (cosΦ=0.4, L/R=7ms) |
| Insulation Resistance (MΩ) | 100 or more (at DC500V insulation resistance meter) |
| Maximum Allowable Contact Current (A) | 1 (for input), 5 (for output) |
| Maximum Allowable Contact Voltage (V) | AC250/DC125 |
| Maximum Opening/Closing Frequency (times/hour) | 18000 (when rated operating voltage is applied, not including contact bounce) (mechanical) |
| Maximum Switching Capacity (VA/W) | (Resistive load) AC440-DC120(Inductive load cosΦ=0.4, L/R=7ms) AC220-DC48 |
| Maximum Switching Frequency (times/hour) | 1800 (when rated operating voltage is applied, not including contact bounce) |
| Maximum Value of Contact Current (A) | 5 |
| Maximum Value of Contact Voltage (V) | AC250, DC125 |
| Mechanical Durability | 50 million times |
| Number of Poles | 1 pole |
| Operating Ambient Temperature (°C) | -40 to +70 (no freezing or condensation) |
| Operating Time (ms) | 15 or less |
| Protection Class | Comes in a case |
| Rated Current (A) | 5 |
| Rated Current (mA) | 21 |
| Recovery Time (ms) | 15 or less |
| Resistive Load (V-A) | DC24-5, AC220-2 |
| Shock Resistance Malfunction (m/s) | 200 |
| Specification | For output |
| Terminal Shape | plug-in terminal |
| Vibration Resistance (Malfunction) | 10～55～10Hz Single amplitude 0.5mm (double amplitude 1.0mm) |
| Withstand Voltage (V/minute) | Between coil and contacts: AC2000 50/60Hz, between contacts of the same polarity: AC1000 50/60Hz |
| types | power relay |
Pilih jenis produk yang diinginkan
| Nomor SKU | Model Number | Masa Persiapan Barang | Harga | Jumlah |
|---|---|---|---|---|
| Loading... | ||||
Apakah produk dengan spesifikasi yang Anda inginkan belum tersedia? Hubungi tim Layanan Pelanggan kami di sini
Informasi Produk
Description
Slim-styled I/O Relay
