Panasonic Latching Relay DPDT 24V dc 1 set of 40 TX2-L2-24V-TH 1set(40pcs)

Name: Panasonic Latching Relay DPDT 24V dc 1 set of 40 TX2-L2-24V-TH 1set(40pcs)
Brand: Panasonic
SKU: S058062173
Price: 8799900 IDR
Availability: InStock

#Nomor SKU S058062173

Wishlist

0 Ulasan

Spesifikasi Produk

Model Number	TX2-L2-24V-TH
Unit	1set(40pcs)
AS ONE Part Number	65-8060-72
M Code	69852739
Berat (Kg)	0.4
Tanggal Produk Terdaftar	25 February 2026
Terakhir Diperbaharui	04 April 2026

Apakah produk dengan spesifikasi yang Anda inginkan belum tersedia? Hubungi tim Layanan Pelanggan kami di sini

Informasi Produk

Description

UL certified, CSA, BSI
TX Series - InrushThis small PCB mount relay allows you to handle 7.5A inrush current. This compact PCB relay also provides high contact capacity and excellent vibration/shock resistance. The relay is sealed for automatic cleaning. Typical applications include air conditioning control and other large capacity control functions.
High sensitivity of 140mW High contact capacitance, 2 A, 30 V dc Supports 7.5 A inrush current

Feature

Specification
*Quantity: 1 tube (40 pieces)*Coil voltage: 24V dc*Contact configuration: DPDT*Mounting type: PCB mount*Maximum switching voltage AC: 250V ac*Maximum switching voltage DC: 220V dc*Maximum switching power DC: 60 W*Length: 15mm*Depth: 7.4mm*Height: 8.2mm*Dimensions: 15 x 8.2 x 7.4mm*Terminal type: Through hole*Switching current: 7.5A*Operating temperature Min: -40°C*Code number: 173-8987
