NKK Switches (formerly Nippon Kaikei) push button switch MB-N12V1S 1pc

Name: NKK Switches (formerly Nippon Kaikei) push button switch MB-N12V1S 1pc
Brand: NKK Switches (formerly Nippon Kaikei)
SKU: S057328034
Price: 179900 IDR
Availability: InStock

#Nomor SKU S057328034

NKK Switches (formerly Nippon Kaikei)

Wishlist

0 Ulasan

Spesifikasi Produk

Model Number	MB-N12V1S
Unit	1pc
Number of Poles	Single pole
Operating Temperature Range (°C)	-30~85
Terminal Shape	printed circuit board vertical
Contact Specifications	Silver
Operation Mechanism	Sold separately: 8 circles/10 circles
Functional Operation	ON-ON
Dimensions, Vertical x Horizontal x Depth (mm)	13x33.18x7.9
Current Capacity	(1)3A125VAC(2)2A250VAC(3)2A30VDC
ROHS Directive (Corresponding to 10 Substances)	Correspondence
M Code	48443887
Berat (Kg)	0.1
Tanggal Produk Terdaftar	20 February 2026
Terakhir Diperbaharui	21 February 2026

Apakah produk dengan spesifikasi yang Anda inginkan belum tersedia? Hubungi tim Layanan Pelanggan kami di sini

Informasi Produk

Description

Basic push button (M series) / Responds to all market needs (126,000 models) / Abundant variations / Special silver alloy contacts / Improved insulation between terminals UL94V-0 case / Improved insulation / High contact area Reliability/Shuts out infiltration of flux, etc.
OA equipment, radio equipment, professional video cameras, switching equipment, electrical measuring instruments, control panels, etc.
*The control unit is sold separately.

Feature

Specification
PC-V terminal type (silver contact): single pole double throw
