Fuji Electric Timer ST7P-2 DC24V 3M 1pc

#Nomor SKU S049846768

Spesifikasi Produk

Model Number	ST7P-2 DC24V 3M
Unit	1pc
Mass (g)	About 45
Type	Super Timer
Type of Sign	surface
Contact Configuration	Time limit 2c
Power Consumption	About 1.1W
Type of Connection	Plug-in type (socket used)
Control Output	3A AC240V (resistive load)
Time	0.25 to 3min
Insulation Resistance (MΩ)	100 or more (at 500V mega)
Operation Indicator	Power on/time up...Red LED
Allowable Ambient Temperature (°C)	-10 to 50 (no freezing or condensation)
Vibration Resistance (Destruction)	10 to 55Hz, double amplitude 0.75mm (1 hour each in 3 axis directions)
Return Time	0.1 seconds or less (including mid-return)
Vibration Resistance (Malfunction)	10 to 55 Hz, double amplitude 0.5 mm (3 axial directions, 10 minutes each)
Mechanical Durability	Over 50 million times (no load, switching frequency 1800 times/hour)
Minimum Applicable Load	5 VDC, 1 mA (reference value)
Setting Error	±10% ±0.02s (maximum scale value)
Operation Mode	On-delay operation
Electrical Durability	Over 500000 times (AC220V 3A resistive load, switching frequency 1800 times/hour)
Allowable Relative Humidity (%)	35 to 85 (no freezing or condensation)
M Code	50266824
Berat (Kg)	0.1
