IDEC RU Series Universal Relay RU2S-C-D110 1box(10pcs)

#Nomor SKU S049171211

Spesifikasi Produk

Model Number	RU2S-C-D110
Unit	1box(10pcs)
Spesifikasi	●Designation code: D110●[Maximum switching frequency] Electrical: 1800 times/hour, Mechanical: 18000 times/hour
Coil Rated Voltage (V)	DC110
Type	Single contact type
Number of Poles	2
Power Consumption (W)	0.9~1
Allowable Current (A)	10
Storage Temperature (°C)	-55 to 70 (no freezing)
Insulation Resistance (MΩ)	100 or more (DC500V mega)
Operation Indicator	Included
Return Time	20 ms or less
Return Voltage	10% or more (initial value) [operating characteristics (at 20°C for rated value)]
Maximum Continuous Applied Voltage	110% [operating characteristics (at 20°C for rated value)]
Mechanical Durability	100 million times or more
Minimum Applicable Load	24 VDC, 5 mA (reference value)
Contact Material	Ag alloy
Shock Resistance (m/s²)	Durability: 1000, Malfunction: 150
Vibration Resistance	Durability: Frequency 10 to 55Hz, half amplitude 0.5mm, Malfunction: Frequency 10 to 55Hz, half amplitude 0.5mm
Minimum Operating Voltage	80% or less (initial value) [operating characteristics (at 20°C against rated value)]
Terminal	Solder terminal
M Code	48019145
Berat (Kg)	0.2
Tanggal Produk Terdaftar	19 November 2025
Terakhir Diperbaharui	15 January 2026
