IDEC NRLY Type circuit protector current trip NRLY2100F-4ABA-5 1pc

Name: IDEC NRLY Type circuit protector current trip NRLY2100F-4ABA-5 1pc
Brand: IDEC
SKU: S049159530
Price: 1399900 IDR
Availability: InStock

#Nomor SKU S049159530

Wishlist

0 Ulasan

Spesifikasi Produk

Model Number	NRLY2100F-4ABA-5
Unit	1pc
Type	With inertial delay
Color	(Locker color) Red transparent, (Body color) Black, (Indicator color) Red
Type of Sign	Snap-on mounting
Number of Poles	2
Rated Voltage (V)	AC250(50/60Hz)
Terminal Shape	(Main terminal) Tab 250 type terminal
Rated Current (A)	4
Operating Patterns	High-speed type (BA characteristics)
Storage Temperature (°C)	-40 to 85 (but no freezing)
Auxiliary Contact	1c micro switch, AC125V/3A (resistance load), DC30V/2A (resistance load)
Insulation Resistance (MΩ)	100 or more (with DC500V mega)
Rated Breaking Capacity (kA)	(AC250V 50/60Hz)0.75 PC1 (UL rating: 1)
Ambient Reference Temperature (°C)	25
Attached Device	None
Internal circuit	Series trip (current trip)
Indicator Lamp	LED(AC/DC24V)
Vibration Resistance	100m/s² (10 to 55Hz) (conditions: when rated current is applied)
Protection Method	Fluid electromagnetic trip method
Durability	Electrical: 10,000 times or more (6 times/min), Mechanical: 20,000 times or more (6 times/min)
Operation Method	Locker type
Withstand Voltage (V/minute)	Between live parts and earth, between opposite polarity terminals, between same polarity terminals (in open circuit), between main circuit and auxiliary contacts AC2000
Shock Resistance	500m/s² (durability, malfunction) (conditions: when rated current is applied, but auxiliary contacts are 360m/s² )
Minimum load	AC/DC24V . 100mA (reference value)
Operating Ambient Humidity (%RH)	45 to 85 (no condensation)
Maximum Tightening Torque (N m)	45 to 85 (no condensation)
M Code	66062237
Berat (Kg)	0.1
