Mitutoyo Digital Indicator Backlight 543-851E 25/0.01mm 1pc

Name: Mitutoyo Digital Indicator Backlight 543-851E 25/0.01mm 1pc
Brand: Mitutoyo
SKU: S045012105
Price: 12999900 IDR
Availability: OutOfStock

#Nomor SKU S045012105

Wishlist

0 Ulasan

Spesifikasi Produk

Model Number	543-851E
Unit	1pc
Digital Step (mm)	0.0005/0.001/0.01
Max. Permissible Error E MPE (mm)	0.0025 (Total Range)
Measuring force MPL (N)	≤1.8
Range (mm)	25.4
Stem Diameter (mm)	8
Alarm	Setting errors, sensor error, display overflow a.s.o.
Contact point	Carbide ball, thread: M2.5x0.45
Display	LCD with red/green backlight, character height 11 mm
Maximum Response Speed	Unlimited
Measurement Frequency	500 times/s (max/min/range)
Power Supply	AC adapter 5,9V, 2A
Protection	IP30
Standard	EN ISO Standard
ABS/INC (INC ZERO)	Yes
Digital Scale	Electrostatic capacitance type absolute linear encoder
Digital Step Switchable	Yes
GO/±NG Judgement	Yes
H MPE (Hysteresis) (mm)	0.002
Inch/Metric Switchable	No
R MPE (Repeatability) (mm)	0.002
Berat (Kg)	0.2
Tanggal Produk Terdaftar	02 January 2025
Terakhir Diperbaharui	15 August 2025

Apakah produk dengan spesifikasi yang Anda inginkan belum tersedia? Hubungi tim Layanan Pelanggan kami di sini

Informasi Produk

Description

This is a superior multifunction indicator.
The ABSOLUTE Digimatic Indicator ID-F offers you the following benefits:
Bidirectional Digimatic S1 interface
Red/Green LCD backlight provides you with visual GO/±NG tolerance judgement
Analogue bar-graph display
MAX/MIN/RANGE (runout value) function with a frequency of 500 times/s
External power supply via AC-Adapter
High accuracy and 0,5 µm digital step
Delivered: Including spindle lifting handle, AC-adapter, certificate of inspection
