Temperature control is an ON/OFF control method.
The temperature display uses a two-stage PV/SV display that allows the actual measured value and set value to be seen at a glance, preventing setting errors.
Equipped with a program function, it is possible to set up to 8 steps and 4 patterns.
Possible to switch between forward and reverse operation.
Equipped with a circuit protector, alarm output function, and sensor abnormality detection function.
AS ONE Digital Temperature Controller (with programmable function) TP-4 Series TP-4NP 1pc
Rp7.199.900
Persediaan
Spesifikasi Produk
| Model Number | TP-4NP |
|---|---|
| Unit | 1pc |
| Power Supply | AC100V 50/60Hz |
| Main Unit Dimensions (mm) | 95 x 150.6 x 48.5 (excluding projections) |
| Sensor Type | Pt100Ω(Φ4x200mm) |
| Temperature Setting (°C) | -199.9 to +199.9 |
| Temperature Control | ON/OFF control |
| Minimum Unit of Display (°C) | 0.1 |
| Additional Functions | Program function/8 steps, 4 patterns |
| Temperature Display Accuracy (°C) | ± 0.5% (FS) ± 1 digit or 3, whichever is greater |
| AS ONE Part Number | 1-5825-22 |
| Temperature Setting Method | Sheet key touch system, PV/SV digital two-stage display |
| Safety Function | Circuit protector (15A), alarm output function, sensor abnormality detection |
| Connection Capacity (A) | MAX12(Resistive Load) AC100V 50/60Hz |
| M Code | 79421644 |
| Berat (Kg) | 0.6 |
| Tanggal Produk Terdaftar | 29 November 2024 |
| Terakhir Diperbaharui | 28 February 2026 |
Apakah produk dengan spesifikasi yang Anda inginkan belum tersedia? Hubungi tim Layanan Pelanggan kami di sini
Informasi Produk
Description
Feature
Temperature control is an ON/OFF control method. The temperature display uses a PV/SV 2-stage display that allows you to see the actual measured value and set value at a glance, preventing setting errors.
Equipped with program function, it is possible to set up to 8 steps and 4 patterns.
Can be switched between forward and reverse operation.
Equipped with circuit protector, alarm output function, and sensor abnormality detection function.
