INA Spherical Plain Bearing GE Type GE35DO-2RS-E 1pc

Name: INA Spherical Plain Bearing GE Type GE35DO-2RS-E 1pc
Brand: INA
SKU: S042047544
Price: 209900 IDR
Availability: InStock

#Nomor SKU S042047544

Wishlist

0 Ulasan

Spesifikasi Produk

Model Number	GE35DO-2RS-E
Unit	1pc
Bore Diameter Bearing (d) (mm)	35
Width Outer Ring C (mm)	20
Ball Diameter (dK) (mm)	47
Tilt Angle (α) (°)	6
Bore Diameter Bearing, Lower Tolerance (dUT) (mm)	-0.012
Outside Diameter, Lower Tolerance (DUT) (mm)	-0.013
Radial Clearance (Gr)	0.05 - 0.1
Width Inner Ring, Lower Tolerance (BUT) (mm)	-0.12
Width Outer Ring, Lower Tolerance (CUT) (mm)	-0.3
Minimum Operating Temperature (Tmin) (°C)	-30
Maximum Operating Temperature (Tmax) (°C)	130
Outside Diameter Bearing (D) (mm)	55
Width Inner Ring B (mm)	25
Basic Dynamic Load Rating, Radial (Cr) (N)	67200
Basic Static Load Rating, Radial (C0r) (N)	306K
Edge Spacing (r1smin) (mm)	0.6
Edge Spacing (r2smin) (mm)	1
Connection Measure Inner Ring (da max) (mm)	39.7
Housing Connection Diameter (Da min) (mm)	45.1
Berat (Kg)	0.2
Tanggal Produk Terdaftar	06 May 2024
Terakhir Diperbaharui	27 January 2026

Apakah produk dengan spesifikasi yang Anda inginkan belum tersedia? Hubungi tim Layanan Pelanggan kami di sini

Informasi Produk

Description

Standard performance Radial spherical plain bearing, requiring maintenance, sliding contact surface: steel/steel, DIN ISO 12240-1, dimension series E, sealed

Warning

- The photo is only a reference (illustration) according to its function
- Product color refers to the product name and specifications listed on the website
- Products received will be in accordance with the information listed on the website.
