TSURUMI PUMP Mass Flow Controller C1050-4S2-50L-H2 1pc
Rp38.999.900
Persediaan
Spesifikasi Produk
| Model Number | C1050-4S2-50L-H2 |
|---|---|
| Unit | 1pc |
| Communication Method | Analog 0 to 5 VDC (D-Sub9 Pin Connector) |
| Drive Power Supply (VDC/mA) | + 15 ±5% 60, -15 ±5% 150 |
| External Leakage Rate (Pa) | 1x10 -7 or less (He) |
| Fitting (inch) | 1/4 SWL equivalent |
| Fluids | gases |
| Gas Service Department Material | SUS316, PTFE, fluorine rubber |
| Input/Output | Analog signal (0 to 5 VDC) |
| Operating Pressure Range (kPa) | 50 to 300 |
| Pressure (MpaG) | 1 |
| Surface Treatments | machining finishes |
| Usable Temperature (°C/%RH) | 5 to 50/85 or less |
| Size (mm) | 160x33.6x105 |
| Reproducibility | . + -. 0.2% FS |
| Flow Rate Accuracy (15-35°C) | . + - . 2% FS |
| Flow Rate Control Range (% FS) | 5 to 100 |
| Flow Rate (SLM) | 50 |
| Gas | H2 |
| Responsiveness (s) | 6 |
| Valve Type | N/O Normal Open |
| Berat (Kg) | 1.0 |
| Tanggal Produk Terdaftar | 28 April 2023 |
| Terakhir Diperbaharui | 27 May 2025 |
Apakah produk dengan spesifikasi yang Anda inginkan belum tersedia? Hubungi tim Layanan Pelanggan kami di sini
Informasi Produk
Warning
Image on this page only as Representative Image, Please check the specifications of each model number for detailsKetentuan dan Kondisi Barang
