Bridgestone Pass Color PA3506 (with F + adapter on both ends) PA3506-2000 F+F 8001+8001 1pc

Name: Bridgestone Pass Color PA3506 (with F + adapter on both ends) PA3506-2000 F+F 8001+8001 1pc
Brand: Bridgestone
SKU: S032782318
Price: 1999900 IDR
Availability: InStock

#Nomor SKU S032782318

Bridgestone

Wishlist

0 Ulasan

Spesifikasi Produk

Model Number	PA3506-2000 F+F 8001+8001
Unit	1pc
Mass (g/m)	550
Material	Inner tube / oil resistant synthetic rubber, jacket / wear resistant weather resistant synthetic rubber, fitting / SS / SC equivalent steel, galvanized / chromated
Maximum Operating Pressure (MPa)	34.5
Minimum Bending Radius (mm)	110
Minimum Bursting Pressure (MPa)	138
Recommended Ambient Temperature (°C)	-40 to +70 (oil), 0 to +70 (water)
Reinforcing Layer	2W
Approximate Mass (g)	Clasp / 100
Suitable fluid	Mineral hydraulic oil, water
Thread Size	G3/8
Connection Thread	Parallel female thread for pipe (Female 30° sheet)
Dimension X (mm)	22
Dimension Y (mm)	19
Fitting length (L) (mm)	62
Fluid Temperature Range (°C)	-40 to +100 (oil), 0 to +60 (water)
Hose Inner Diameter (Φmm)	9.5
Hose Outer Diameter (Φmm)	19.2
Length (mm)	2000
Length L (mm)	2000
M Code	70399857
Berat (Kg)	1.5
Tanggal Produk Terdaftar	26 July 2022
Terakhir Diperbaharui	15 August 2025

Apakah produk dengan spesifikasi yang Anda inginkan belum tersedia? Hubungi tim Layanan Pelanggan kami di sini

Informasi Produk

Description

Long life and high fatigue resistance Compact hydraulic piping with a small bending radius A wide range of products suitable for pump rated pressure
JIS K6349-3 (High pressure rubber hose) JIS B8360 (High pressure rubber hose assembly) Compliant product For general hydraulic piping

Use

For general hydraulic piping
