ABB Power Supply CP-D 24/0.42 1unit

Name: ABB Power Supply CP-D 24/0.42 1unit
Brand: ABB
SKU: S032534252
Price: 2499900 IDR
Availability: InStock

#Nomor SKU S032534252

Wishlist

0 Ulasan

Spesifikasi Produk

Model Number	CP-D 24/0.42
Unit	1unit
Pollution Degree	2
Product Depth/Length (mm)	57.5
Product Height (mm)	91
Product Width (mm)	18
Characteristic of Output	Hiccup-mode
Connecting Capacity Input Circuit (mm²)	Flexible with Ferrule 0.2-1.5, Rigid 0.2-2.5
Connecting Capacity Output Circuit (mm²)	Flexible with Ferrule 0.2-2.5, Rigid 0.2-2.5
Input Voltage (V)	90-264 AC, 120-375 DC
Minimum Mounting Distance (mm)	Electrical Conductive Board (horizontal 25, Vertical 25), Other Device Same Type (Horizontal 25, Vertical 25)
Number of Phases	1
Maximum Output Current (A)	0.42
Output Current (A)	0.42
Output Power (W)	10
Output voltage (V)	24
Rated Frequency Limits (Hz)	47-63
Rated Frequency (Hz)	50, 60
Rated Impulse with Stand Voltage (kV)	Input Circuit / Output Circuit 3
Degree of Protection	Housing IP20, Terminals IP20
Mounting on DIN Rail (mm)	TH35-15 (35x15 Mounting Rail) acc. to IEC 60715, TH35-7.5 (35x7.5 Mounting Rail) acc. to IEC 60715
Berat (Kg)	0.1
Tanggal Produk Terdaftar	14 July 2022
Terakhir Diperbaharui	27 May 2025

Apakah produk dengan spesifikasi yang Anda inginkan belum tersedia? Hubungi tim Layanan Pelanggan kami di sini

Informasi Produk

Description

CP-D 24/0.42 Power supply In: 100-240VAC Out: 24VDC/0.42A
The CP-D 24/0.42 is a power supply from the CP-D range. The primary switch mode power supply offers a wide range input of 90-264 V AC and 120-375 V DC, rated input voltage is 100-240 V AC. The rated output power is 10 W, rated output current is 0.42 A at an output voltage of 24 V DC. The power supply provides a U/I output characteristic.
