OMRON Safety Guard Switching Unit G9SX G9SX-GS226-T15-RT DC24 1pc
Rp10.999.900
Persediaan
Spesifikasi Produk
| Model Number | G9SX-GS226-T15-RT DC24 |
|---|---|
| Unit | 1pc |
| Withstand Voltage (V/minute) | Logical connection Input terminal ⇔ Power supply / other input / output terminals batch, all terminals batch ⇔ DIN rail: AC500 . |
| Tightening Strength (N m) | (Terminal) 0.5 |
| Function | Safety guard switching unit |
| Operating Time (ms) | (OFF to ON) When safety input is ON: 50 or less, when logical connection input is ON: 100 or less |
| Response Time | (ON → OFF) 15ms or less |
| Terminal Block | Screw terminal block |
| Ambient Relative Humidity (RH) | 25 to 85 |
| Rated Voltage (V) | DC24 |
| Maximum Set Time (s) | Off-delay time: 15 |
| Insulation Resistance (MΩ) | Logic connection input terminal ⇔ Power supply, other I / O terminals, all terminals ⇔ Between DIN rails: 20 or more DC100V Mega |
| Vibration Resistance Frequency (Hz) | 10 to 55 to 10 Single amplitude 0.375mm (Double amplitude 0.75mm) |
| Leakage Current (mA) | OFF: 0.1 or less (safety output, auxiliary output), 1 or less (external Indicator light output) |
| Impact Resistance Durability (m/s²) | 300 |
| Wiring Length (m) | 100 or less (for safety input and logic connection input) (External connection impedance: 100Ω or less and 10nF or less) |
| Mode Switching (ms) | Mode switching input switching allowable time: 450 or less Operation mode switching response time: 50 or less |
| Output Configuration | (Safety instantaneous output) 2 outputs, (Safety off-delay output) 2 outputs, (Auxiliary output) 6 outputs |
| Operating Ambient Temperature (°C) | -10 to +55 (with no icing or condensation) |
| Voltage (V) | Residual voltage when ON: 3.0 or less (safety output, auxiliary output, external indicator output Reset input time (reset pressing time): 100ms or more |
| M Code | 39071347 |
| Berat (Kg) | 0.1 |
| Tanggal Produk Terdaftar | 28 June 2022 |
| Terakhir Diperbaharui | 27 May 2025 |
