Mitutoyo Digital Height Gauge 192-664-10 HDM-60AX 600/0.01mm 1pc

Name: Mitutoyo Digital Height Gauge 192-664-10 HDM-60AX 600/0.01mm 1pc
Brand: Mitutoyo
SKU: S030181410
Price: 19999900 IDR
Availability: InStock

#Nomor SKU S030181410

Wishlist

0 Ulasan

Spesifikasi Produk

Model Number	192-664-10
Unit	1pc
Units	Metric
Measurement Range (mm)	0 to 600
Accuracy (mm)	±0.04
Standard Accessories	05GZA033, 905200
Battery	SR44 (1 pc.) 938882
Battery Life	Approx. 2,000 hours under normal use
Display	LCD
Optional Accessories	192-007, 192-008, 900306, 900321, 900322, 905338, 905409, 905691, 905692, 953639
Technology	Digimatic
SPC Output	Yes
Maximum Response Speed (mm/s)	500
Resolution (mm)	0.005
Selectable Resolution	Yes
Mitutoyo Part Number	HDM-60AX
M Code	10174997
Berat (Kg)	1.0
Tanggal Produk Terdaftar	13 December 2021
Terakhir Diperbaharui	21 January 2026

Apakah produk dengan spesifikasi yang Anda inginkan belum tersedia? Hubungi tim Layanan Pelanggan kami di sini

Informasi Produk

Description

The highly versatile Mitutoyo multi-function digital height gage provides precise height measurements combined with an optional bi-direction touch probe signal to measure step, inside width and outside width. The included carbide-tipped long scriber is extremely durable and provides highly accurate marks on your workpiece. Measurements are shown on an easy-to-read LCD display.

Warning

Image on this page only as Representative Image, Please check the specifications of each size and color for details

Feature

Available in Metric and Inch/Metric models
Metric models are available in three measurement ranges
Inch/Metric models are available in four measurement ranges
An optional bi-directional touch signal probe is available for to quick and accurate measurement of steps, and inside and outside widths
Resolution is switchable between 0.005mm/.0002” and 0.01mm/.0005”
Display features large LCD characters (11mm in height) for easier measurement reading and to reduce eye strain
Large function buttons on display are positioned for easy operation
Inclined slider handle improves slider ergonomics
Rigid construction ensures repeatable measurements
Base is shaped to provide a secure grip
Coarse/fine feeding switch for fast adjustments and precise measurements
Functions include Zero setting, ABD/INC switching, 2 Presets, Probe tip diameter compensation, -/+ switching, Power On/Off, Data hold, Data output, and inch/mm conversion (on inch/metric models only)
Alarm: Low Voltage, Counting Value Composition Error

Use

Function:
- Origin setting function (ABS measurement system)
- Zero setting function (INC measurement system)
- Origin return function
- Preset function (ABS/INC measurement system)
- Direction switching function
- Hold function
- Error warning function
- Measurement data output function
- Coarse/fine movement switching
- Low battery voltage warning
- Ball diameter correction
