Reduces wiring and man-hours with crimp connector terminals Reduces wiring with crimp connectors. Space saving is also achieved by extending the terminals laterally.
The actuator is available in two directions. Increased flexibility in mounting switches.
The same mounting pitch as the SS ultra-small basic switch.
OMRON Ultra-Compact Basic Switch D3M D3M-01L1 1pc
Rp47.900
Persediaan
Spesifikasi Produk
| Model Number | D3M-01L1 |
|---|---|
| Unit | 1pc |
| Allowable Operating Speed (mm-m/s) | 0.1 to 1 (Pin pushbutton type) |
| Protection Class | IEC IP40 |
| Type Of Actuator | Hinge / lever type |
| Minimum Applicable Load (V-mA) | DC5-1 |
| Operating Ambient Temperature (°C) | -25 to +85 60% RH or less (with no icing or condensation) |
| Rated Voltage (V) | DC30 |
| Button Color | Red |
| Contact Configuration | 1b (normally closed Type) |
| Withstand Voltage | Between terminals of the same polarity: 1000 VAC, 50/60 Hz for 1 min Between live metal parts and ground, between each terminal and non-live metal parts: Between each terminal and non-live metal parts: 1500 VAC, 50/60 Hz for 1 min |
| AS ONE Part Number | 64-3355-95 |
| Insulation Resistance (MΩ) | 100 or more (with DC500V insulation resistance meter) |
| Ambient Relative Humidity (RH) | 80 or less (at +5 to + 35 °C) |
| Contact Resistance (miliΩ) | 100 or less (initial value) (value including resistance of connector and lead wire (AWG # 28 length 50mm)) |
| Operating Force OF (N) | Up to 1.00 |
| Vibration Resistance (Malfunction) | Frequency 10 ~ 55Hz, double amplitude 1.5mm (operating limit position) |
| Mechanical Durability | 500,000 operations or more (60 operations / min) |
| Resistive Load (A) | 0.1 |
| Return Force (N) | 0.10 min |
| Electrical Durability | 200,000 operations or more (30 operations / min) |
| Contact Specifications | Crossbar |
| M Code | 46550996 |
| Berat (Kg) | 0.5 |
| Tanggal Produk Terdaftar | 23 November 2021 |
| Terakhir Diperbaharui | 07 February 2026 |
Apakah produk dengan spesifikasi yang Anda inginkan belum tersedia? Hubungi tim Layanan Pelanggan kami di sini
Informasi Produk
Description
Feature
Conditioning with a crimping connector terminal, an minimal wiring and a capacity saving data can be distributed by a crimping connector. Terminal also achieves space saving by lateral drawer. Actuators provide two directions. Switch mounting freedom expansion.
SS Mt. SS Ultra-small base switch and mounting pitch identical.
