The circuit is reliably shut off with two-circuit double break.
Structure that conforms to IP67 with O-rings and cover seals.
UL, CSA, TUV, EN/IEC and CCC certifications are obtained, making it ideal for machinery for export.
High precision type ideal for position control. The movement up to the movement is small (5 degrees) and the repeatability is twice that of the standard type.
The neon lamp or LED can be used to check the operating status, making it easy to check and perform maintenance at start-up.
One-touch connection reduces wiring man-hours.
OMRON 2-Circuit Limit Switches WL-N/WLG Series WLGCA2-55LD General Type 1pc
Rp1.599.900
Persediaan
Spesifikasi Produk
| Model Number | WLGCA2-55LD |
|---|---|
| Unit | 1pc |
| Inrush Current (A) | Always closed: up to 30 Always open: up to 20 |
| Mechanical Durability (times) | 10 million or more |
| Allowable Operating Speed (mm-m/s) | 1 to 1 (for WLCA2) |
| Allowable Operation Frequency (times/minute) | Mechanical: 120 Electrical: 30 |
| Electrical Durability (times) | 500,000 or more |
| Electric Shock Protection Class | Class I |
| Short Circuit Protection Device (A) | 10 fuse gG or gI (IEC269) |
| Shock Resistance Mis Operation (m/s²) | 300 or more |
| Rated Sealed Thermal Current (A) | 10, 0.5 (EN60947-5-1) |
| Pollution Degree (Environment to Use) | 3 (EN60947-5-1) |
| Operation | Reference value Movement until movement PT: 5° (0 to 2 °) Movement after movement OT (minimum) : 40 ° |
| Operating Force OF (N) | Up to 13.34 |
| Earth Terminal | None |
| Return Force (N) | Reference value RF (minimum) : 1.47 |
| Head specifications | (One side operation) x, (Head mounting) Possible in 4 Directions |
| Conditional Short Circuit Current (A) | 100 (EN60947-5-1) |
| Vibration Malfunction Frequency (Hz) | 10 to 55 Double amplitude 1.5mm |
| Operation Indicator Lamp | Light emitting diode (LED) |
| Ambient Relative Humidity (RH) | 35-95 |
| Protection Class | IP67 |
| M Code | 35459961 |
| Berat (Kg) | 0.5 |
| Tanggal Produk Terdaftar | 23 November 2021 |
| Terakhir Diperbaharui | 31 March 2026 |
Apakah produk dengan spesifikasi yang Anda inginkan belum tersedia? Hubungi tim Layanan Pelanggan kami di sini
Informasi Produk
Description
Feature
2 Circuits are reliably blocked by circuit twice.Structure adapted to IP67 by O-ring or cover seal.
We have acquired UL, CSA, TUV, EN/IEC, CCC standard certification, so it is ideal for machine export.
High precision type optimal for position control. Movement to operation is small (5 degrees) and repetitive accuracy has achieved twice the reference type.
Neon lamps or LEDs can check the operating status and can easily check and maintain at startup.
Reduce the number of wiring steps with one touch connection.
