Sumitomo Electric Insert TPGN TPGN160308 H1 1box(10pcs)
Rp2.099.900
Persediaan
Spesifikasi Produk
| Model Number | TPGN160308 H1 |
|---|---|
| Unit | 1box(10pcs) |
| With Or Without Hole | None |
| Slot | Without hole |
| Nose Radius r (mm) | 0.8 |
| Material | H1 |
| Thickness Tolerance (mm) | +/- 0.13 |
| Inscribed Circle Diameter (phi mm) | 9.525 |
| Cutting Blade Length (mm) | 16.5 |
| Inscribed Circle Tolerance (mm) | +/- 0.025 |
| Shape | Equilateral triangle 60 degrees |
| Grade | Grade G |
| Corner Radius (mm) | 0.8 |
| Corner Height Tolerance (mm) | +/- 0.025 |
| Chip breaker | None |
| Clearance Angle (degree) | 11 |
| Thickness (mm) | 3.18 |
| Manufacturer Conventional Part Number | TPG322 |
| M Code | 05922926 |
| Berat (Kg) | 0.9 |
| Tanggal Produk Terdaftar | 26 August 2020 |
| Terakhir Diperbaharui | 24 November 2025 |
