onsemi onsemi Op-amp, Surface Mount, 4 Circuits, ±2 Power Supplies, Single Power Supply, LM324DR2G

Specification
*Mounting type: Surface mount*Package type: SOIC*Power supply type: ±2 supplies, single supply*Number of circuits: 4*Number of pins: 14*Standard single supply voltage: 5 -> 28 V*Standard dual supply voltage: ±12 V, ±15 V, ±3 V, ±5 V, ±9 V*Maximum operating temperature: +70°C*Standard voltage gain: 100 dB*Height: 1.5 mm*LM324*LM224*LM2902*NCV2902*Single supply*Quad op amp*ON Semiconductor. The ON Semiconductor LM324/LM224/LM2902/NCV2902 quad op amps feature true differential inputs and operate with supply voltages from 3 V to 32 V. The common-mode input range includes the negative supply, eliminating the need for external bias components in many applications. The output voltage range also includes the negative supply voltage. Four amplifiers per package Short-circuit protected outputs True differential input stage Single supply operation: 3 to 32 V Low input bias current: 100 nA maximum (LM324A) Internal compensation Input ESD clamps improve stability without affecting device operation
