SAMTEC Samtec PCB Header, 500 Position, 1.27mm, 10 Rows, SEAM-50-02.0-S-10-2-AK-TR

Specification
*Series: SEAM*Pitch: 1.27mm*Number of Positions: 500*Number of Rows: 10*Connection Orientation: Straight*Shrouded/Unshrouded: Shrouded*Connector System: Board-to-Board*Termination Method: Solder*Surface Finish: Contact: Gold*Current Rating: 1.8A*Voltage Rating: 240.0V*1.27 mm SEARAY(TM) Series Interconnects. SEARAY(TM) is a 1.27 mm high-density/high-speed board-to-board interconnect system. This SEAM/SEAF series connector can be mapped for single-ended or differential pair applications. When routed as a single-ended system, SEARAY(TM) is rated to 12.5 GHz @ -3 dB. This SEAM/SEAF series high-speed/high-density open pin field array utilizes Solder Charge Technology for exceptional solder joint reliability. The SEAM SEAF series SEARAYTM high-speed/high-density open pin field array utilizes Samtec's edge-rate contact system for high-speed performance, zippered mating, and extremely low insertion and withdrawal forces. High-density connectors with a variety of row counts, ideal for board stacking applications. Stack heights from 7 mm up, depending on the SEAF/SEAM combination. Contact resistance: 5.5 mΩ. Contact plating: 0.76 μm gold on contact area, matte tin on tail area.
