BULGIN USB connector, USB2.0, male Bulgin, number of ports: 1

Specification
Male/Female: Male * Mounting type: Panel mount * Terminal method: Plug-in * USB version: 2.0 * Body orientation: Straight * Number of ports: 1 * Rated current: 1A * Rated voltage: 30 V ac * Series: USB * Series Number: PX0848 * Contact material: Copper alloy * Operating temperature Min: 0°C * Operating temperature Max: +70°C * Dust/sealing cap is also available. 468-6248 For 468-6248, see 468-6333 468-6333. For 468-6327 468-6327 and 468-6311 468-6311, see 504-4588 504-4588. The connector with a cable shown does not have a rear cable gland seal. Bulgin Buccaneer Shielded USB Data Connector. USB A Sealed End-Standard USB B type and USB B Sealed End-Standard USB A comprehensive cable assembly products. Various types and lengths are available including Type A / Type B USB front/rear panel mount sealed connectors. The screw-coupling USB connector is dustproof and waterproof, 1.5 Mbs -> 480 Mbs low/high speed bus connection, high noise immunity, and RoHS compliant when mated in a position with easy-to-see mating indicators (IP68 and IP69K). Exhibits EMI protection performance. Ideal for applications such as PCs and peripherals.
