SAMTEC Samtec Board Connection Header IsoRate IP5 Series

Specification
Series: IsoRate IP5, Pitch: 4mm, Number of Contacts: 6, Number of Rows: 1, Body Orientation: Straight, Shrouded/Unshrouded: Shrouded, Connector System: Board-to-Board, Termination Method: Solder, Type: Board-to-Board, Voltage Rating: 200 ac. Samtec IP5 Series 4.00 mm 50 Ohm High-Isolation Board-to-Board and Wire-to-Board RF Plug Strip. The IP5 Series 50 Ohm High-Isolation Board-to-Board and Wire-to-Board RF Plug Strip features a 4.00 mm contact pitch and a 10 mm BTB stack height. This IP5 4.00 mm RF plug strip is part of the IsoRate High-Isolation Interconnect System, which performs up to 9.5 GHz and 19 Gbit/s. The IsoRate interconnect system features rugged edge-rated contacts, providing high isolation at a lower cost than traditional turned RF contacts. The IP5 Series High-Isolation RF Plug Connector is available in single- and dual-row configurations with up to eight jacks per row. Part numbers ending in "L-TR" are IP5 wire-to-board RF plug strips with cable latches. This IP5 4.00 mm RF plug connector mates with IJ5 RF jack connectors (for board-to-board applications) and IJ5C high-insulation RF cable assemblies (for wire-to-board applications).
