Panasonic SMD Resistor, 5.6kΩ, 0603 (1608M), 0.1W ERA3APB562V
#Grup produk P115619429
Spesifikasi
| Maximum Operating Temperature (°C) | 155 |
|---|---|
| Minimum Operating Temperature (°C) | -55 |
| ROHS Directive (Corresponding to 10 Substances) | Correspondence |
| Rated Power (W) | 0.1 |
| Resistance (kΩ) | 5.6 |
| Series | ERA |
| Standard | Car: AEC-Q200 |
| Technology | Metal coating |
| Temperature coefficient | ±15ppm/°C |
| Tolerance | ±0.1% |
Pilih jenis produk yang diinginkan
| Nomor SKU | Model Number | Masa Persiapan Barang | Harga | Jumlah |
|---|---|---|---|---|
| Loading... | ||||
Apakah produk dengan spesifikasi yang Anda inginkan belum tersedia? Hubungi tim Layanan Pelanggan kami di sini
Informasi Produk
Feature
SpecificationIEC60115-8, JIS C5201-8, EIAJ RC-2133B. Panasonic 0.1 W ERA Series 0.1% 15 ppm, 330 Ω to 7.5 kΩ. Panasonic's ERA 3A metal film resistors are stable and maintain high accuracy even in high-temperature and humid environments. This series of 0603 chip resistors provides a high-performance solution and features excellent nonlinearity. Features and Benefits: AEC-Q200 qualified, low temperature coefficient of resistance, tight resistance tolerance, excellent linearity and low current noise, power rating options: 0.05 W to 0.25 W. Applications: This metal thin film resistor is AEC-Q200 qualified and suitable for automotive applications.
