Panasonic Relay 5V dc, 2c contact, PCB mounting type
#Grup produk P115569522
Spesifikasi
| Coil Voltage (V) | 5/dc |
|---|---|
| Contact Configuration | DPDT |
| Maximum Switching Voltage (AC V) | 440 |
| Maximum Switching Voltage (DC V) | 30 |
| Number of Poles | 2 |
| ROHS Directive (Corresponding to 10 Substances) | Correspondence |
| Series | SF2D |
| Switching Current (A) | 6 |
| Terminal Type | Through hole |
| Type of Sign | Board mounting |
Pilih jenis produk yang diinginkan
| Nomor SKU | Model Number | Masa Persiapan Barang | Harga | Jumlah |
|---|---|---|---|---|
| Loading... | ||||
Apakah produk dengan spesifikasi yang Anda inginkan belum tersedia? Hubungi tim Layanan Pelanggan kami di sini
Informasi Produk
Feature
SpecificationEN50205 Type A, IEC60664-1 III/4kV. cUL, TUV, SEV. Force-guided safety relay - SF2 series. Used in machinery, appliances, and equipment that must meet special safety requirements (press, combustion, railway, medical). Maximum switching voltage: 400 V. Operating temperature range: -40 to +70°C. Contact material: AgSnO 2 , Au flash.
