RS PRO RS PRO standard DIN rail terminal ZRK series

Specification
Series: ZRK Cable Size: 20 to 12 AWG Cable CSA: 2.5mm2 Color: Blue Rated Current: 27A Number of Levels: Double Terminal Method: Spring Rated Voltage: 600 V Operating Temperature Min: -40°C Operating Temperature Max: +120°C Spring Terminals. A range of spring feed-through DIN rail terminals with a proven tension spring connection system for the smallest cross-sections from 0.2 mm2 to 16 mm2. The system allows for safe and quick connection of solid and stranded wires with or without wire termination ferrules. The ground terminal has a PE foot contact snap-on to ensure mechanical and electrical safety on both sides of the terminal despite the absence of screws.
