RS PRO RS PRO SMP connector
#Grup produk P115433591
Spesifikasi
| ROHS Directive (Corresponding to 10 Substances) | Correspondence |
|---|
Pilih jenis produk yang diinginkan
| Nomor SKU | Model Number | Masa Persiapan Barang | Harga | Jumlah |
|---|---|---|---|---|
| Loading... | ||||
Apakah produk dengan spesifikasi yang Anda inginkan belum tersedia? Hubungi tim Layanan Pelanggan kami di sini
Informasi Produk
Feature
SpecificationGender: Female, Male; Retention: Limited Detent; Body Orientation: Straight; Termination Method: Solder; Mounting Type: PCB Mount; Battery Type: Standard; Body Plating: Gold; Cable Type: Coaxial; Impedance: 50 Ω; Mating Type: Snap-on; Operating Frequency: 18 GHz; Contact Plating: Gold; Contact Material: Brass; RS 50 Ω SMP RF Coaxial Board Mount Limited Detent Plug Receptacle Connector. This 50 Ω SMP RF Coaxial Board Mount Limited Detent Plug Receptacle connector features a gold-plated brass body and a mechanical interface conforming to MIL-STD-348A. This 50 Ω SMP RF Coaxial Board Mount Limited Detent Plug Receptacle connector features four 1.05 mm diameter solder legs (2.54 mm pitch) and an overall height of 7.4 mm. For more information about this 50 Ω SMP RF Coaxial Board Mount Limited Detent Plug Receptacle, please refer to the datasheet on the manufacturer's website.
