The RS PRO series mechanical pin sockets offer a full range of extremely high quality and reliable DIP package sockets.
The manufacturer's sockets feature a solid precision-turned sleeve with a closed-bottom design to prevent flux intrusion and solder wicking during soldering.
Stamped copper inserts provide excellent connectivity and allow for repeated mating and unmating.
Plating options include gold, tin, or selective gold plating.
The insulator is made from high temperature thermoplastic resin.
High voltage contacts, precision stamped internal spring contacts, anti-solder wick design, machine insertable, single or dual row, low profile
RS PRO RS PRO DIL Socket, 2.54mm Pitch, 14 Pin
#Grup produk P115293692
Spesifikasi
| ROHS Directive (Corresponding to 10 Substances) | Correspondence |
|---|
Pilih jenis produk yang diinginkan
| Nomor SKU | Model Number | Masa Persiapan Barang | Harga | Jumlah |
|---|---|---|---|---|
| Loading... | ||||
Apakah produk dengan spesifikasi yang Anda inginkan belum tersedia? Hubungi tim Layanan Pelanggan kami di sini
Informasi Produk
Description
Feature
SpecificationNumber of poles = 14
Mounting type = Through-hole mounting Applicable pin contact = Turn pitch = 2.54mm
Column width = 7.62mm
Wiring Method = Solder Rated Current = 3A
Length = 17.78mm
Width = 10.16mm
Depth = 3mm
Dimensions = 17.78 x 10.16 x 3mm
Operating temperature Min = -40°C
