RS PRO Multi timer RS PRO SPDT 400V ac 17.5mm
#Grup produk P115233195
Spesifikasi
| ROHS Directive (Corresponding to 10 Substances) | Correspondence |
|---|
Pilih jenis produk yang diinginkan
| Nomor SKU | Model Number | Masa Persiapan Barang | Harga | Jumlah |
|---|---|---|---|---|
| Loading... | ||||
Apakah produk dengan spesifikasi yang Anda inginkan belum tersedia? Hubungi tim Layanan Pelanggan kami di sini
Informasi Produk
Feature
SpecificationMonitoring application: Phase, voltage * Power supply voltage: 400 V ac * Contact configuration: SPDT * Voltage sensitivity: overvoltage, undervoltage * Electrical phase: 3 * Voltage detection range: 300 -> 380 V ac (voltage shortage), 420 -> 500 V ac (overvoltage) * Phase sensitivity: phase disturbance, phase sequence * Delay time: 0.2 -> 10 seconds * Frequency detection range: 48 -> 63 Hz * Dimensions: 17.5 x 66.5 x 89 mm * UL recognized. LX series-three-phase relay. The timers, controls and three-phase relays of the L Series relay products are equipped with the latest technology and have a wide range of user-selectable functions. .17.5 mm DIN Rail Housing Microprocessor Base Measures Phase-to-Phase Voltage SPDT Relay Output 8 A x 1 Green LED Indicator for Power Status Red LED Indicator for Relay Status
